The MBT 301 is a multi-technology system with two, individually controlled, universal handpiece channels. The system features a two-line back lit LCD display. The programmable features include: password protection from unauthorized changes, a user definable temperature operating range, and “SetBack” & “Auto-Off” functions to preserve tip life. PACE’s MBT 301 is a self contained, 2 channel rework station that offers high capacity, low temperature SMT/Thru-Hole soldering, desoldering and repair. The unit features 2 individually powered and controlled handpiece channels, providing the capability to run 2 different IntelliHeat handpieces simultaneously, and at different temperatures.
- Two channel rework system
- Soldering, desoldering, and hot air functionality
- Programmable, digital controls
- Compatible with 8 IntelliHeat handpieces
- Both channels can be used simultaneously, and at different temperatures
- Power station only – for a package containing handpieces, please see 8007-0478 on this page
Pace MBT301 Rework Power Unit Specifications
- Air Flow Rating: 8SLPM
- Depth: 9.25″
- Height: 5.3″
- Lead Free Solder Compatible: Yes
- Type: Digital
- Width: 6.5″
- Voltage Rating: 120VAC
- Frequency Rating: 50/60Hz
- Pressure Rating: 18psi
- Temperature Stability: ?±2°F
- Tip to Ground Resistance: <2Ohms
- Vacuum Rating: 20in. Hg
- Vacuum Rise Time: 150ms.
