BAG, STATSHIELD, METAL-OUT, ZIP 8”x10”, 100 EA/PACK

• Aluminum metal outer layer of laminated film
  Metal out required by many end users
• 40% light transmission
  Allows for identification of bag contents
• Integral antistatic, low tribocharging properties
  Bag contents will not electrostatically charge during movement
• Integral static dissipative properties
  Not topically treated, not humidity dependant, won’t wear off
• Manufactured on specially designed soft fold converting machines
  Prevents scratches and creases maintaining the integrity of Faraday Cage shielding protection
• Large 3/8″ wide seals – high performance interior sealing layer
  Greater sealing surface provides greater seal strength compared to comparable products with 1/8″ wide seals; higher quality, more durable
• Identified with ESD Protective Symbol as required by ANSI/ESD S541 with lot code #.
  Improved quality control tracking and identified as ESD packaging.
• Lot coded
  Quality control traceability
• Polycarbonate compatible containing no amines or N-octanic acid
  Non-corrosive, will not contaminate parts
• Testable to industry standards
  Meets or exceeds one or more of the following standards: electrical and physical requirements of ANSI/ESD S20.20, ANSI/ESD S541, EIA 541, EIA 625, MIL-STD-1686, and EIA 583
• Antistatic, low charging, reclosable zipper
  Available with heat-sealable opening
• Use labels to close shielding bags and seal ESD protective packaging
• Lead-free RoHS compliant

• Made in the United States of America
  This item is made and stocked in Canton, MA

  Estimated Shipping Weight: 2.28 Pounds

The bag’s material meets the performance specification requirements of ANSI/ESD S541.

Sold in packages of 100 bags packaged in a protective oversized ESD bag.

Resistance of outer surface: <10E8 ohms
Resistance of inner surface: <10E11 ohms
Thickness: Nominal .0030″ (.0762mm) ±10%

ANSI/ESD S541 Section 6.2 Outside an EPA:

Transportation of sensitive products outside of an EPA shall require packaging that provides:

1. Low charge generation

2. Dissipative or conductive materials for intimate contact

3. A structure that provides electrostatic discharge shielding.”

Desco’s bags are recyclable

Mixed unsortable plastic scrap shall contain assorted plastics of multiple grades that are co-extruded, bonded or laminated together which are unsortable into individual grades.

Desco ESD Bags Are Generally Reusable

For best results, bag inventory should be continually replenished. It is recommended that standard packs of bags should be stored in its original packaging in a climate controlled environment where the temperature ranges from 45 degrees F to 70 degrees F and relative humidity is 50%. Bags should not be stored in ultraviolet sunlight, moisture, or heat because the aluminum shielding layer could oxidize if exposed to these conditions.
