BAG, STATSHIELD, METAL-OUT, ZIP 5”x8”, 100 EA/PACK

$31.54

Product SKU: 13230
Minimum Order Quantity: 1
Manufacturer: Desco

Check/Validate Stock Quantity New!

Our goal is to become your #1 source for electronic production supplies. With thousands of available products from top brands, we have everything your business needs to function at its best.

  • Promotion: Free shipping
  • Fast shipping with tracking on your account
  • 30 Day Satisfaction Guarantee
  • Phone or Email Customer Service

In stock

Description
    • Aluminum metal outer layer of laminated film
      Metal out required by many end users
    • 40% light transmission
      Allows for identification of bag contents
    • Integral antistatic, low tribocharging properties
      Bag contents will not electrostatically charge during movement
    • Integral static dissipative properties
      Not topically treated, not humidity dependant, won’t wear off
    • Manufactured on specially designed soft fold converting machines
      Prevents scratches and creases maintaining the integrity of Faraday Cage shielding protection
    • Large 3/8″ wide seals – high performance interior sealing layer
      Greater sealing surface provides greater seal strength compared to comparable products with 1/8″ wide seals; higher quality, more durable
    • Identified with ESD Protective Symbol as required by ANSI/ESD S541 with lot code #.
      Improved quality control tracking and identified as ESD packaging.
    • Lot coded
      Quality control traceability
    • Polycarbonate compatible containing no amines or N-octanic acid
      Non-corrosive, will not contaminate parts
    • Testable to industry standards
      Meets or exceeds one or more of the following standards: electrical and physical requirements of ANSI/ESD S20.20, ANSI/ESD S541, EIA 541, EIA 625, MIL-STD-1686, and EIA 583
    • Antistatic, low charging, reclosable zipper
  • Use labels to close shielding bags and seal ESD protective packaging
  • Lead-free RoHS compliant
  • Made in the United States of America
    This item is made and stocked in Canton, MAEstimated Shipping Weight: 1.24 Pounds

The bag’s material meets the performance specification requirements of ANSI/ESD S541.

Sold in packages of 100 bags packaged in a protective oversized ESD bag.

Resistance of outer surface: <10E8 ohms
Resistance of inner surface: <10E11 ohms
Thickness: Nominal .0030″ (.0762mm) ±10%

ANSI/ESD S541 Section 6.2 Outside an EPA:

“Transportation of sensitive products outside of an EPA shall require packaging that provides:

1. Low charge generation

2. Dissipative or conductive materials for intimate contact

3. A structure that provides electrostatic discharge shielding.”



Desco’s bags are recyclable

Mixed unsortable plastic scrap shall contain assorted plastics of multiple grades that are co-extruded, bonded or laminated together which are unsortable into individual grades.



Desco ESD Bags Are Generally Reusable

For best results, bag inventory should be continually replenished. It is recommended that standard packs of bags should be stored in its original packaging in a climate controlled environment where the temperature ranges from 45 degrees F to 70 degrees F and relative humidity is 50%. Bags should not be stored in ultraviolet sunlight, moisture, or heat because the aluminum shielding layer could oxidize if exposed to these conditions.
