- Most commonly used shielding bag meets limits of ANSI/ESD S541 per ANSI/ESD S20.20.
High volume manufacturing provides value for the customer
- 40% light transmission
Allows for easy identification of bag contents
- Integral antistatic, low tribocharging properties
Bag contents will not electrostatically charge during movement
- Integral static dissipative properties
Not topically treated, not humidity dependant, won’t wear off
- Manufactured on specially designed soft fold converting machines
Prevents scratches and creases maintaining the integrity of Faraday Cage shielding protection
- Large 3/8″ wide seals – high performance interior sealing layer
Greater sealing surface provides greater seal strength compared to comparable products with 1/8″ wide seals; higher quality, more durable
- Identified with ESD Protective Symbol as required by ANSI/ESD S541 with lot code #.
Improved quality control tracking and identified as ESD packaging.
- Polycarbonate compatible containing no amines or N-octanic acid
Non-corrosive, will not contaminate parts
- Testable to industry standards
Meets or exceeds one or more of the following standards: electrical and physical requirements of ANSI/ESD S20.20, ANSI/ESD SS41, EIA 541, JESD625-A, MIL-STD-1686, and EIA 583
- Use labels to close shielding bags and seal ESD protective packaging
- Lead-free RoHS compliant
- Made in the United States of America
This item is made and stocked in Canton, MA.
Sold in packages of 100 bags packaged in a protective oversized ESD bag.
Resistance of outer surface: <10E11 ohms per ANSI/ESD S11.11
Resistance of inner surface: <10E11 ohms per ANSI/ESD S11.11
Thickness: Nominal .0030″ (.0762mm) ±10%
Technical Requirements and Guidance
ESD protective packaging shall be in accordance with the contract, purchase order, drawing or other documentation. When not specified by the above documentation, the organization shall define ESD protective packaging requirements, both inside and outside the EPA per ANSI/ESD S541. [ANSI/ESD S20.20-2007 section 8.4]
